MANUFACTURING & QUALITY

Don’t Take Our

Word for It.

See Our Factory Live.

See how FBU machines critical components, controls drawings and BOMs, inspects selected critical dimensions, assembles complete cartridge seals and air-leak tests every complete unit before shipment.

Critical components machined in-house Inspection according to plan

Every complete cartridge air-leak tested

about-fbu
FROM DRAWING TO SHIPMENT
A controlled route to a tested cartridge seal.
Manufacturing equipment matters, but control across engineering, production, inspection, testing and repeat supply is what makes the result dependable.

01

Engineer

02

Machine

03

Inspect

04

Assemble & Test

05

Release for Repeat Supply

五轴五联动2
CRITICAL‑COMPONENT MANUFACTURING
Precision CNC machining for critical seal components.
FBU uses HAAS CNC equipment to machine critical metal components under
controlled drawings and production requirements.

Sleeves

Glands

Seal-Ring Holders

Other Critical Metal Parts

Public boundary: HAAS machining capability and operations may be shown. Detailed equipment models, quantities and equipment inventory are available within an authorized audit scope, not published online.

INSPECTION ACCORDING TO PLAN
Selected critical dimensions. Inspected according to plan.
ZEISS inspection is applied to selected critical dimensions and components according to the inspection plan.

Sleeve

Gland

Seal-Ring Holder

Rotating Seal Face

Stationary Seal Face

Defined Critical Dimensions

This is not presented as 100% ZEISS inspection of every dimension or every component. Measuring and testing equipment is managed through defined calibration planning and control.

检验1
检验2
检验3
检验4
COMPLETE‑CARTRIDGE ASSEMBLY
Factory-assembled as a complete cartridge seal.
FBU supplies complete, factory-built cartridge mechanical seals. Components are assembled under controlled production information before final inspection and air-leak testing.

01 · CONTROLLED INPUTS

Components, Drawing & BOM

Production uses the applicable configuration, controlled component identity and current manufacturing information.

02 · FACTORY ASSEMBLY

Complete Cartridge Construction

The new seal is completed at FBU—not delivered as loose parts for the customer to assemble.

03 · FINAL CONTROL

Inspection, Testing & Identity

The complete cartridge moves through final control before documented shipment and repeat supply.

气密性测试
COMPLETE‑CARTRIDGE TESTING
Every complete cartridge seal is air-leak tested before shipment.
The test result is linked to the product identity, and an air-leak test report is supplied with each complete cartridge seal.

Product Serial Number

Test Pressure

Hold Time

Test Medium

Leakage Acceptance Criteria

Test Date

Operator & Inspector

Test Result

DOCUMENTATION, SYSTEMS & TRACEABILITY
Know what was supplied. Find it again when you need it.
Every FBU cartridge seal is supplied with clear product identification and installation information, with inspection records retained for traceability.

SAP

Order-to-Delivery Coordination

SAP supports order, production and delivery coordination.

PLM

Controlled Product Definition

PLM controls 3D models, drawings, BOMs, revisions and product records.

Product Records

Identification & Traceability

Inspection and test information remains linked to controlled production records.

Aftermarket

Repeat Seals & Repair Kits

Customer part numbers and repair-kit continuity support the installed base.
QUALITY MANAGEMENT AND CERTIFICATE SCOPE
Recognized systems. Claims kept inside their scope.
Management-system certifications and product certificate scope are shown separately so customers can understand what each document actually covers.

API Spec Q1

10th Edition · Registration Q1-5423 · Valid through April 22, 2028. Scope: design, manufacture and sale of mechanical seals for the oil and gas industry.

QMS CERTIFICATION

ISO 9001:2015

LRQA Approval 00045125 · Certificate 10614905 · Valid through June 12, 2027. Scope includes design, production and custom processing of mechanical seals.


QMS CERTIFICATION

ISO 14001:2015

LRQA Approval 00050926 · Certificate 10726764 · Valid through October 26, 2028. Scope includes design, production and customized processing services of mechanical seals.

EMS CERTIFICATION

ATEX

EUROCERT 25 ATEX 0599 · Technical documentation receipt certificate · Valid through February 8, 2036. Applies only to the listed product models, configurations and markings.

PRODUCT SCOPE APPLIES

Clear API boundary: API Spec Q1 registration is a quality-management-system certification. It is not a blanket API product certification, API Monogram authorization or API 682 product approval.

SEE IT LIVE. THEN AUDIT WHAT MATTERS.
Start with 30 minutes.
Expand the review when useful.
The first step is a focused, interactive Microsoft Teams factory tour. Formal remote and onsite audits are arranged around the customer’s supplier-qualification plan.

STEP 01

30-Minute Teams Factory Tour

See the process live and ask questions with FBU sales, engineering and project delivery. This is an interactive video meeting—not a prerecorded presentation.

STEP 02

Formal Remote Audit

Review relevant engineering, manufacturing, inspection, test and system evidence against your audit plan.

STEP 03

Onsite Supplier Audit

Follow your agenda with the management representative and relevant FBU functions participating according to scope.

Sales

Engineering

Project Delivery
